| Optical Parameters | |
| Light source type | LED |
| Resolving power | 1280*720P |
| Brightness | 150ANSI |
| Uniformity | 68% |
| Contrast | 1000:01:00 |
| Projective ratio | 1.3: 1 |
| Optimum projection size | 40~120 inch |
| Aspect ratio | 4:3、16:9、16:10 |
| Focus mode | Manual focus |
| Noise | <40dB（1m） |
| Horn | 4Ω 3W |
| Machine power | 35W（Max） |
| Service life | 30000 hours |
| Working temperature | -10℃～60℃ |
| Storage temperature | -20℃～70℃ |
| Storage humidity | 10% ~ 80% |
| USB Port | USB2.0 HOST × 1 |
| Display Port | Supports HDMI 2.0 input × 1 |
| Audio interface | Headset output × 1 |
| IR | IR × 2 |
| System Parameters | |
| System Version | Android 11 |
| UI system | Neutral English system |
| WLAN | Supports 2.4G/5G WiFi6 |
| Supports BT5.4 | |
| Language | Simplified Chinese, Traditional Chinese, English, Russian, Spanish... |
| Projection mode | Support front projection and formal installation/front projection and lifting/rear projection and formal installation/rear projection and back installation |
| Automatic keystone correction | Support |
| Screen Zoom | Support 60%-100% |
| Wireless screen projection | Support |
| Other Parameters | |
| Machine size | 103*103*204mm |
| Package size | 135*140*240mm |
| Main parameters of Product | |
| Product Name | Portable Projector |
| Model | P30 |
| SOC | H713 |
| CPU | Quad-core 64 bit ARM Cortex™-A53 |
| GPU | ARM Mali-G31 |
| Supports OpenGL ES 3.2, Vulkan 1.1, and OpenCL 2.0 | |
| RAM | Supports：1GB/2GB |
| ROM | Supports：8GB/16GB |
| Supports： | |
| - 10-bit HEVC MP@L6.1, up to 4K@30fps | |
| VPU | - 10-bit VP9, up to 4k@30fps |
| - 10-bit AVS2, up to 4K@30fps | |
| - 8-bit AVC BP/ MP/ HP@ L4.2, up to 4K@30fps | |
| - MPEG1 MP/ML, MPEG2 MP/HL, and MPEG4 SP/ASP L5, up to 1080P@60fps | |
| - 10-bit AV1 MP/L5.1, up to 1080P@60fps | |
| Main Interface Function | |
| AC输入 | 100~240V |
| Carton Size | 420*450*498mm |
| N.W/G.W | 0.62kg/0.86kg |
| PCS/CTN | 18PCS |
| G.W/CTN | 16.5kg |
| Accessories | IR Remote Control*1 |
| AC Power Cable*1 | |
| User Manual*1 | |
